Zeiss Milvus 50/1.4 vs Zeiss Otus 55/1.4 vs Zeiss Planar 50/1.4 – Comparative Lens Review
Field Test – CA Control
Just like in our previous review of the 85mm equivalents this is a test area (CA), where we can see most of the differences in the optical performance.
Scene 01 image is representing background in the park. Very cloudy day with gray sky.
(Please use your mouse to hover over image to reveal left or right crop. Use arrows bellow the window to switch to the other pair of images. Usually there are three comparative pairs – Otus vs Milvus, Otus vs Planar, Milvus vs Planar.)
Scene 01 f/1.4
Scene 01 f/2.8
Scene 01 f/7.1
Scene 02 is representing dark contrast on the blue sky. Sunny day, late sun.
Scene 02 f/1.4
Scene 02 f/5.6
Finally, let’s take a look at the small test target that is good for axial CA correction level indication.
LensCal at f/1.4
LensCal at f/2.8
Looking at all posted (CA test) samples, it becomes clear where three Zeiss lenses differs most. Otus is almost CA free, we can push it to extremes where purple fringing is visible, but those are situations that one will hardly experience willingly. Milvus has greatly improved spherical aberration in comparison to the Planar, but it doesn’t improve as much in color aberration correction. Big question is – how much is that important for you? There are always photographers who would claim that removing purple fringing is easy in post processing. This is sometimes true, but sometimes it’s not that easy or at least results are not 100% perfect and different artifacts could arise.
BTW in our MTF measurements (we repeated them twice) we found Otus to show less astigmatism in whole aperture range than Milvus, unlike some other testing sites. Our results for Otus were around 7.5%, while Milvus gets to just bellow 9%. At f/4 and smaller, both lenses gets to negligible difference between horizontal and vertical MTF50.
Field Test – Flare Resistance
Zeiss Otus 55/1.4 at f/1.4
Zeiss Milvus 50 f/1.4 at f/1.4
Zeiss Planar 50/1.4 at f/1.4
Zeiss Otus 55/1.4 at f/5.6
Zeiss Milvus 50/1.4 at f/5.6
Zeiss Planar 50/1.4 at f/5.6
Flare resistance of Zeiss lenses is probably one of the attributes that company is most proud of. Famous T* coating is a legend in the industry and while silently updated from time to time, even old Zeiss lenses with red T* letter, have great performance in back or side lit situations. It’s not only about flares that could appear (those are also depending on the sensor reflection), but if you look at images above, you should admire high level of preserved contrast.
Planar is just a small step behind Otus and Milvus, but honestly, I won’t be afraid to shot in a direct sunlight with any of those optics.
>To help this page survive, your donation will be highly appreciated.
regarding the manual focusing. I recently tried the Zeiss 85mm f/1.4 Milvus with the new D5 and I think that the the smaller focus points may make it possible to manual focus with the lens. Unfortunately, I did have a few issues, for some reason the focus point wasn’t visible for some reason on the D5, when manually focusing, I was told that the camera didn’t have release firmware. But when I reviewed the shot, it did show where the focus point was placed and the image did look sharp. So fingers crossed it is a big improvement.
Great, let us know how it works for you at full opened aperture, once you manage to fine tune it.
Cheers,
Viktor
I don’t own the D5, so it might be a while, I do want to try it with the D500, to see if the camera will manual focus accurately with the added pixel density of the camera, which will be closer to a D820 (I am guessing it will have more than 36mp).
Where would you put the Zeiss 50mm makro-planar in this equation of Milvus, Otys and classic planar? I see you have done a review of macro 50mm lenses but I believe the classic makro-planar belongs here due to f2 speed and focal length.
Personally I’m impressed that a planar design performs so well wide open at f2 but I don’t know how it compares to the new Milvus. The Otus, I know what to expect as I have 135mm f2 APO.
Hi Nat,
I haven’t compare macro lenses directly, I reviewed Milvus 50/14 and compared it with Otus 55 and Classic Planar 50. Macro Planar 50/2 was optimized for the short distances where it achieves very good resolution figures in the center of the frame. As a most macro lenses it has rather flat focus field and very long focus thread. I don’t know where I will put it in the above mentioned comparison, because I didn’t test it for other usage than product shots (mainly short working distances). I am very happy with the lens for that type of work.
Hope it helps,
Viktor
Thank you for your reply. I guess it’s apples to oranges in a way. People used to compare makro-planar to the f1.4 classic back when there were only two Zeiss 50mm lenses. Nowadays it’s 4 50mm lenses from Zeiss alone not to mention the offerings from third parties such as Tamron Sigma and Nikon already has more than 10 lenses in the 50mm range.
So far I’m happy with 50mm f2 zf as a general purpose lens. Zeiss 25mm f2 is slightly superior with off center resolution and coma (but it is a distagon that has aspherical and anamalous elements ). The 25mm f2 is then trashed by 135mm f2 APO if I attempt a technical comparison and go off-focus and off-axis.
Hi Viktor, so I finally got to test the 85 milvus vs. the loxia side by side. I can’t tell you which is sharper. What I can tell you is that I purchased milvus 85 and it’s on its way – what a gorgeous lens!
Anyway, I’m also thinking of picking up the milvus 50. I understand its optical pros/cons about as well as I can based off your literature/testing (please keep up the great work!), and others.
What I’m curious about is the feel of the focus on the milvus 50. I was concerned about the stiffness on 85 before I got it, but it does not bother me. Is the 50 focus stiffer than the 85?
Hi Micah,
sorry for the late reply. Congrats on your new lens, Milvus 50 has same focus stiffness as 85, don’t worry.
Cheers,
Viktor
thank u very much for this review, i am art photographer and user of 50mm 1.4 planar ZE and love it much
Actually Zeiss lenses aren’t that hard to nail focus with. You need to train first but after that it’s a lot easier.
Don’t trust the red focus point blink, instead look for focus/ae lock in the camera viewfinder.
Hi Gustav and thank you for the opinion. I don’t trust red blinker, but at open apertures, it is very difficult to nail eyeball instead of eyebrows in my experience. Could be just me though…
Cheers,
Viktor
